DON'T DAMAGE YOUR PROJECTOR, TODAY YOU CAN PROTECT IT FROM THE WEATHER AND DUST!

Designed, patented and produced WEATHER PROTECTION CLIMATIZED CASE to protect your projector from all kinds of weather conditions: temperature changes, cold, dust, smog, fog and humidity! It is a new device that allows you to install the projector anywhere outdoors.

Weather has always been a problem for us as dust and fog and low temperatures interfere with project installations and restrict the passage of light by penetrating the image-generating DLP and LCD systems.

Before introducing the weather protection case, we found a significant decrease in light intensity when the projector was placed in an open area exposed from the weather, and a significant decrease in brightness after 2 months. So we created a new device that allows these projectors to be installed anywhere outside without fear of damage.

It can accommodate projectors of all sizes, from small projectors (3000 Ansi Lumens) to large video projectors used for video mapping (55.000 Ansi Lumens). Made with great design, our Weather Proof cases can be used with all kinds of projectors. If our standard model does not have the right dimensions for your machine, please contact us.

ALL MODELS ARE CUSTOMIZABLE ACCORDING TO YOUR VIDEO PROJECTOR

vrain_6k_videoproiezioni_esterno_protezi

CASE AF6

WEATHERPROOF OUTDOOR PROJECTOR ENCLOSURE PATENTED

Our outdoor projector enclosure AF6, thanks to its heating and cooling system, allows the installation of any beamer in any weather condition. The fiberglass case, unlike metal, prevents condensation inside the box.

With our waterproof, protective housing you will be able to have perfect year-round outdoor projections and video mappings without having to worry about heat, cold, dust rain or snow.

Furthermore, an internal filter purifies the entering air permitting the best possible working conditions. If connected H24 to the electrical current, the AF6 protection performs an automatic temperature check and activates the heating and cooling system both during the day (when the projector is switched off) and at night when the projector is working.

The AF6 has also been designed to be installed to the ceiling or, in general, to any suitable support structure.

Our outdoor projector housing is suitable for video projector up to 6k ANSI lumen and if it doesn't suit your video projector, we can customize it!

dimensioni_protezione_proiettore_6k-B.pn

TECHNICAL DATA

Maximum dimension of the insertable video projector:
width 480 mm – height 200 mm – depth 360 mm*
*an additional length space of 50 mm is available for the lens

WEIGHT: 22kg (without the projector inside)

CONSUMPTION:

100 W max – while cooling
200 W max – while heating

CASE AF10


WEATHERPROOF OUTDOOR PROJECTOR ENCLOSURE PATENTED

Our outdoor projector enclosure AF10, thanks to its heating and cooling system, allows the installation of any video projector in any weather condition. The fiberglass case, unlike metal, prevents condensation inside the box.

With our waterproof, protective housing you will be able to have perfect year-round outdoor projections and video mappings without having to worry about heat, cold, dust rain or snow.

Furthermore, an internal filter purifies the entering air permitting the best possible working conditions. If connected H24 to the electrical current, the AF10 protection performs an automatic temperature check and activates the heating system in case of cold weather and the cooling system in case of hot climate conditions.

The AF10 has also been designed to be installed to the ceiling or, in general, to any suitable support structure.

Our outdoor projector housing is suitable for video projector up to 10k ANSI lumen and if it doesn't suit your video projector, we can customize it!

dimensioni_vrain_10.000_GUSCIO_VIDEOPROI

TECHNICAL DATA

Maximum dimension of the insertable video projector:
width 530 mm – height 250 mm – depth 500 mm*
*an additional length space of 50 mm is available for the lens

WEIGHT: 32kg (without the projector inside)

CONSUMPTION:

100 W max – while cooling
200 W max – while heating


CASE AF20

WEATHERPROOF OUTDOOR PROJECTOR ENCLOSURE PATENTED

Our outdoor projector enclosure AF20, thanks to its heating and cooling system, allows the installation of any beamer in any weather condition. The fiberglass case, unlike metal, prevents condensation inside the box.

With our waterproof, protective housing you will be able to have perfect year-round outdoor projections and video mappings without having to worry about heat, cold, dust rain or snow.

Furthermore, an internal filter purifies the entering air permitting the best possible working conditions. If connected H24 to the electrical current, the AF20 protection performs an automatic temperature check and activates the heating and cooling system both during the day (when the projector is switched off) and at night when the projector is working.

The AF20 has also been designed to be installed to the ceiling or, in general, to any suitable support structure.

Our outdoor projector housing is suitable for video projector up to 20k ANSI lumen and if it doesn't suit your video projector, we can customize it!


TECHNICAL DATA

Maximum dimension of the insertable video projector:
width 570 mm – height 350 mm – depth 760 mm*
*an additional length space of 60 mm is available for the lens

WEIGHT: 53kg (without the projector inside)

CONSUMPTION:

150 W max – while cooling
300 W max – while heating

25K-outdoor-exterior-projector-proietta-

CASE AF32

WEATHERPROOF OUTDOOR PROJECTOR ENCLOSURE PATENTED

Our outdoor projector enclosure AF32, thanks to its heating and cooling system, allows the installation of any video projector in any weather condition. The fiberglass case, unlike metal, prevents condensation inside the box.

With our waterproof, protective housing you will be able to have perfect year-round outdoor projections and video mappings without having to worry about heat, cold, dust rain or snow.

Furthermore, an internal filter purifies the entering air permitting the best possible working conditions. If connected H24 to the electrical current, the AF32 protection performs an automatic temperature check and activates the heating system in case of cold weather and the cooling system in case of hot climate conditions.

The AF32 has also been designed to be installed to the ceiling or, in general, to any suitable support structure.

Our outdoor projector housing is suitable for video projector up to 32k ANSI lumen and if it doesn't suit your video projector, we can customize it!

dimensione_protezione_proiettori_25k-B.p

TECHNICAL DATA

Maximum dimension of the insertable video projector:
width 650 mm – height 350 mm – depth 850 mm*
*an additional length space of 140 mm is available for the lens

WEIGHT: 100kg (without the projector inside)

CONSUMPTION:

300 W max – while cooling
300 W max – while heating


CASE AF40

WEATHERPROOF OUTDOOR PROJECTOR ENCLOSURE PATENTED

Thanks to its heating and cooling system, AF40 is our most popular outdoor projector enclosure solution . This climate-controlled housing allows the installation of any video projector in any weather condition. The fiberglass case, unlike metal, prevents condensation inside the box. With our waterproof, temperature-controlled, dust-tight enclosure you will be able to have perfect environmental projections and video mappings without having to worry about heat, cold, dust rain or snow.

Furthermore, an internal filter purifies the entering air permitting the best possible working conditions. If connected H24 to the electrical current, the AF40 protection performs an automatic temperature check and activates the heating system in case of cold weather and the cooling system in case of hot climate conditions.

The AF40 has also been designed to be installed to the ceiling or, in general, to any suitable support structure. Our outdoor projector housing is suitable for video projector up to 40k ANSI lumen and if it doesn't suit your video projector, we can customize it!


TECHNICAL DATA

Maximum dimension of the insertable video projector:
width 800 mm – height 485 mm – depth 1300 mm*
*an additional length space of 200 mm is available for the lens

WEIGHT: 144kg (without the projector inside)

CONSUMPTION:

400 W max – while cooling
400 W max – while heating

exp55K-exterior-projector-staffa-alta-pr

CASE AF55

WEATHERPROOF OUTDOOR PROJECTOR ENCLOSURE PATENTED

Our outdoor projector enclosure AF55, thanks to its heating and cooling system, allows the installation of any video projector in any weather condition. The fiberglass case, unlike metal, prevents condensation inside the box.

With our waterproof, protective housing you will be able to have perfect year-round outdoor projections and video mappings without having to worry about heat, cold, dust rain or snow.

Furthermore, an internal filter purifies the entering air permitting the best possible working conditions. If connected H24 to the electrical current, the AF55 protection performs an automatic temperature check and activates the heating system in case of cold weather and the cooling system in case of hot climate conditions.

The AF55 has also been designed to be installed to the ceiling or, in general, to any suitable support structure.

Our outdoor projector housing is suitable for video projector up to 55k ANSI lumen and if it doesn't suit your video projector, we can customize it!

dimensione_protezione_proiettori_25k-B.p

TECHNICAL DATA

Maximum dimension of the insertable video projector:
width 890 mm – height 511 mm – depht. 1250 mm

CONSUMPTION:

400 W max – while cooling
400 W max – while heating
